MIL-PRF-19500/534G
TABLE I. Group A inspection. - Continued.
Symbol
Unit
Inspection 1/
MIL-STD-750
Limits
Method
Conditions
Min
Max
Subgroup 2 - Continued
Forward - current
3076
VCE = 5 V dc, IC = 50 mA dc.
hFE1
transfer ratio
2N5002
20
2N5004
50
Forward - current
3076
VCE = 5 V dc, IC = 2.5 A dc,
hFE2
transfer ratio
pulsed (see 4.5.1).
2N5002
30
90
2N5004
70
200
Forward - current
3076
VCE = 5 V dc, IC = 5 A dc,
hFE3
transfer ratio
pulsed (see 4.5.1).
2N5002
20
2N5004
40
1.45
V dc
Base-emitter voltage
3066
VBE
Test condition B, VCE = 5 V dc,
(non-saturated)
Base-emitter saturation
3066
1.45
V dc
VBE(sat)1
Test condition B, IC = 2.5 A dc,
voltage
Base-emitter saturation
3066
2.2
V dc
VBE(sat)2
Test condition B, IC = 5 A dc,
voltage
0.75
V dc
Collector-emitter
3071
VCE(sat)1
IC = 2.5 A dc, IB = 250 mA dc,
saturation voltage
pulsed (see 4.5.1).
Collector-emitter
3071
1.5
V dc
VCE(sat)2
IC = 5 A dc, IB = 500 mA dc,
saturation voltage
pulsed (see 4.5.1).
Subgroup 3
High-temperature operation:
TC = +150°C.
Collector to emitter cutoff
3041
500
µA dc
ICES3
Bias condition A; VCE = 60 V dc,
current
VBE = 0.
Low-temperature operation:
TC = -55°C.
Forward-current
3076
VCE = 5 V dc, IC = 2.5 A dc,
hFE4
transfer ratio
pulsed (see 4.5.1).
15
2N5002
25
2N5004
See footnotes at end of table.
