MIL-PRF-19500/534G

TABLE I. Group A inspection. - Continued.

Symbol

Unit

Inspection 1/

MIL-STD-750

Limits

Method

Conditions

Min

Max

Subgroup 5 - Continued.

Safe operating area

3053

TC = +25�C, RBB1 = 10Ω,

(unclamped inductive)

RBB2 = 100Ω, L = 0.3 mH,

RL = 0.1Ω, VCC = 10 V dc,

VBB1 = 10 V dc, VBB2 = 4 V dc,

ICM = 10 A dc (see figure 7).

End-point electrical

See subgroup 2 of table I.

measurements

Subgroups 6 and 7

Not applicable

1/ For sampling plan, see MIL-PRF-19500.

2/ For resubmission of failed in subgroup 1 of table I, double the sample size of the failed test or sequence of tests.

A failure in table I, subgroup 1 shall not require retest of the entire subgroup. Only the failed test shall be rerun upon

submission.

3/ Separate samples may be used.

4/ Not required for JANS devices.

5/ Not required for laser marked devices.

6/ This hermetic seal test is an end-point to temp-cycling in addition to electrical measurements.

7/ This test is required for the following end-point measurements only:

Group B, subgroups 3, 4, and 5 (JANS).

Group B, step 1 (JAN, JANTX, and JANTXV).

Group C, subgroups 2 and 6.

Group E, subgroups 1 and 2.
