MIL-PRF-19500-557 Semiconductor Device, Field Effect Transistor, N-Channel, Silicon Types 2N6796, 2N6796U, 2N6798, 2N6798U, 2N6800, 2N6800U, 2N6802, And 2N6802U Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for a N-channel, enhancement-mode, MOSFET, power transistor intended for use in high density power switching applications. Three levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14

MIL-PRF-19500/557L

Dimensions

Inches

Millimeters

Ltr

Min

Max

Min

Max

.345

.360

8.77

9.14

.280

.295

7.11

7.49

.095

.115

2.41

2.92

LL1

.040

.055

1.02

1.40

LL2

.055

.065

1.40

1.65

.050 BSC

1.27 BSC

LS1

.025 BSC

0.635 BSC

LS2

.008 BSC

0.203 BSC

.020

.030

0.51

0.76

.105 REF

2.67 REF

.120 REF

3.05 REF

.045

.055

1.14

1.40

.070

.080

1.78

2.03

.120

.130

3.05

3.30

NOTES:

Dimensions are in inches.

Millimeters are given for general information only.

In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.

Ceramic package only.

FIGURE 2. Physical dimensions for LCC.
