The documentation and process conversion
INCH-POUND
measures necessary to comply with this
revision shall be completed by 1 October 2014.
MIL-PRF-19500/560L
1 August 2014
SUPERSEDING
MIL-PRF-19500/560K
2 October 2010
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, SWITCHING,
TYPE 2N5339 AND 2N5339U3, JAN, JANTX, JANTXV, JANS, JANSM, JANSD, JANSP, JANSL,
JANSR, JANSF, JANSG, JANSH, JANHCC, JANKCC, JANKCCM, JANKCCD, JANKCCP,
JANKCCL, JANKCCR, JANKCCF, JANKCCG, and JANKCCH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN silicon switching transistors. Four
levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500 and two
levels of product assurance are provided for each unencapsulated device type as specified in MIL-PRF-19500.
Provisions for radiation hardness assurance (RHA) to eight radiation levels is provided for JANS and JANKC product
assurance levels. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to
identify devices, which have passed RHA requirements.
1.2 Physical dimensions. See figure 1 (TO-39), figure 2 for U3 devices (TO-276AA) and figures 3 and 4 for
JANHC and JANKC (die) dimensions.
1.3 Maximum ratings Unless specified, TA = 25°C.
Types
PT (1)
PT (1)
TJ and TSTG
RθJC
VCBO
VCEO
VEBO
IC
IB
RθJA
TA = +25°C
TC = +25°C
°C/W
°C/W
°C
W
W
V dc
V dc
V dc
A dc
A dc
2N5339
1.0
17.5
175
10
100
100
6.0
5.0
1.0
-65 to +200
2N5339U3
1.0
75
2.3
100
100
6.0
5.0
1.0
-65 to +200
(1) For derating, see figures 5, 6, and 7.
1.4 Primary electrical characteristics TA = +25°C. (Unless otherwise indicated, applies to all devices.)
hFE1 (1)
hFE2 (1)
hFE3 (1)
Limits
VCE = 2.0 V dc; IC = 0.5 A dc
VCE = 2.0 V dc; IC = 2.0 A dc
VCE = 2.0 V dc; IC = 5.0 A dc
Min
60
60
40
Max
240
(1) See note at end of 1.4.
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST Online
database at https://assist.dla.mil .
AMSC N/A
FSC 5961
