MIL-PRF-19500-560 Semiconductor Device, Transistor, Npn, Silicon, Switching, Type 2N5339 And 2N5339U3, Jan, Jantx, Jantxv, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, Jansh, Janhcc, Jankcc, Jankccm, Jankccd, Jankccp, Jankccl, Jankccr, Jankccf, Jankccg, And JankcchThis specification covers the performance requirements for NPN silicon switching transistors. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500 and two levels of product assurance are provided for each unencapsulated device type as specified in MIL-PRF-19500. Provisions for radiation hardness assurance \(RHA\) to eight radiation levels is provided for JANS and JANKC product assurance levels. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


MIL-PRF-19500/560L
Symbol
Dimensions
Notes
Inches
Millimeters
Min
Max
Min
Max
CD
5
.305
.355
7.75
9.02
CH
.240
.260
6.10
6.60
HD
3
.335
.370
8.51
9.40
LC
.200 TP
5.08 TP
6
LD
.016
.021
.41
.53
7
LL
.500
.750
12.70
19.05
7
LU
.016
.019
.41
.48
7
L1
.050
1.27
7
L2
.250
6.35
7
TL
.029
.045
.74
1.14
3
TW
.028
.034
.71
.86
10
P
.100
2.54
5
Q
.050
1.27
4
r
.010
.25
10, 11
α
45° TP
45° TP
6
Notes
1, 2, 8, 9
1, 2, 8, 9
NOTES:
1.
Dimensions are in inches.
2.
Millimeters are given for general information only.
3.
Symbol TL is measured from HD maximum.
4.
Details of outline in this zone are optional.
5.
Symbol CD shall not vary more than .010 (0.25 mm) in zone P. This zone is controlled for automatic
handling.
6.
Leads at gauge plane .054 inch (1.37 mm) +.001 inch (0.03 mm) -.000 inch (0.00 mm) below seating plane
shall be within .007 inch (0.18 mm) radius of true position (TP) relative to tab. Device may be measured by
direct methods or by gauge.
7.
Symbol LD applies between L1 and L2. Dimension LD applies between L2 and LL minimum.
8.
Lead designation, depending on device type, shall be as follows:
Lead number
TO-39
1
Emitter
2
Base
3
Collector
9.
Lead number three is electrically connected to case.
10.
Beyond r maximum, TW shall be held for a minimum length of .011 inch (0.28 mm).
11.
Symbol r applied to both inside corners of tab.
In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.
12.
FIGURE 1. Physical dimensions (TO-39) - Continued.
4
