MIL-PRF-19500/560L

TABLE III. Group E inspection (all quality levels) - for qualification and requalification only.

MIL-STD-750

Inspection

Qualification

Method

Conditions

45 devices

Subgroup 1

c=0

Temperature cycling

1051

Test condition C, 500 cycles.

(air to air)

Hermetic seal

1071

Fine leak

Gross leak

Electrical measurements

See table I, subgroup 2 herein.

Subgroup 2

45 devices

c=0

Intermittent life

1037

VCB = 10 V dc, 6,000 cycles. Adjust device current, or

power, to achieve a minimum ĆTJ of +100�C.

Electrical measurements

See table I, subgroup 2 herein.

Subgroups 4

Thermal impedance

See MIL-PRF-19500.

curves

Subgroup 5

Not applicable

Subgroup 8

45 devices

c=0

Reverse stability

1033

Condition B.
