MIL-PRF-19500-590 Semiconductor Device, Diode, Silicon, Ultrafast Recovery, Power Rectifier, 1N6626 Through 1N6631, 1N6626U Through 1N6631U, 1N6626Us Through 1N6631Us, Jan, Jantx, Jantxv, And JansThis specification covers the performance requirements for a silicon, ultrafast recovery, semiconductor power rectifier diode. Four levels of product assurance are provided for each device type as specified in

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


MIL-PRF-19500/590K
10
Design Limit
5
1
0.5
10
20
0.1
1
0.001
0.01
He ating Time (se c)
ZθX = 1.5ºC/W at 10 ms
RθJEC = 6.5ºC/W
FIGURE 4. Surface mount thermal impedance.
