MIL-PRF-19500/607B
* TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Symbol
Limits
Units
Method
Conditions
Min
Max
Subgroup 3
TC = TJ = +125°C
High temperature
operation:
± 200
IGSS2
nA dc
Gate current
3411
VGS = +20 V dc and -20 V dc,
bias condition C, VDS = 0
Drain current
3413
Bias condition C, V GS = 0 V
1.0
mA dc
IDSS2
N-channel
VGS = 80 percent of rated VDS
0.25
mA dc
IDSS3
VDS = 100 percent of rated VDS
-1.0
mA dc
IDSS2
P-channel
VGS = 80 percent of rated VDS
mA dc
-0.25
IDSS3
VDS = 100 percent of rated VDS
Static drain to source
3421
Pulsed (see 4.5.1), ID = ID2
rDS(on)3
on-state resistance
Ω
N-channel
VGS = 10 V
1.4
Ω
P-channel
VGS = -10 V
1.4
VDS ≥ VGS,
Gate to source
3403
VGS(th)2
voltage (threshold)
N-channel
ID = 0.25 mA dc
1.0
V dc
P-channel
ID = -0.25 mA dc
-1.0
V dc
TC = TJ = -55°C
Low temperature
operation:
VDS ≥ VGS,
Gate to source
3403
VGS(th)3
voltage (threshold)
N-channel
ID = 0.25 mA dc
5.0
V dc
P-channel
ID = -0.25 mA dc
-5.0
V dc
Subgroup 4
Switching time test
3472
ID = ID1, VGS = 10 V dc,
RG = 24Ω(N-ch), RG = 18Ω (P-
ch), VDD = 50 percent
of rated V(BR)DSS
Turn-on delay time
td(on)
N-channel
VGS = 10 V
20
ns
P-channel
VGS = -10 V
30
ns
Rise time
tr
N-channel
VGS = 10 V
25
ns
P-channel
VGS = -10 V
60
ns
