MIL-PRF-19500-610 Semiconductor Device, Hermetic, Diode, Silicon, Schottky Barrier, Types 1N6677-1 And 1N6677Ur-1, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for silicon, Schottky barrier diodes. Four levels of product assurance are provided for each encapsulated device types as specified in MIL-PRF-19500, and two levels of product assurance for each unencapsulated device type die.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


MIL-PRF-19500/610F
DO-213AA
Symbol
Dimensions
Inches
Millimeters
Min
Max
Min
Max
BD
.063
.067
1.60
1.70
ECT
.016
.022
0.41
0.56
BL
.130
.146
3.30
3.71
S
.001 min
0.03 min
NOTES:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
FIGURE 2. Physical dimensions of surface mount family, 1N6677UR-1 (DO-213AA).
3
