4.2.1 Group E inspection. Group E inspection shall be conducted in accordance with MIL-PRF-19500 and 4.4.4
herein.
4.2.2 JANHC and JANKC devices. Qualification for JANC devices shall be in accordance with appendix G of
MIL-PRF-19500. This testing may be performed on a TO-5 package in lieu of the axial leaded package.
4.3 Screening (JAN, JANTX, JANTXV, and JANS levels only). Screening shall be in accordance with table E-IV of
MIL-PRF-19500, and as specified herein. The following measurements shall be made in accordance with table I
herein. Devices that exceed the limits of table I herein shall not be acceptable.
4.3 Screening (JAN, JANTX, JANTXV, and JANS levels only) - Continued.
Measurement
Screen (see table
E-IV of
JANS level
JANTX and JANTXV level
JAN level
1a
Required
Not required
Not required
1b
Required
Required (JANTXV only)
Not required
2
Not required
Not required
Not required
3a
Required
Required
Required in accordance
with MIL-PRF-19500,
JANTX level
3b
Not applicable
Not applicable
Not applicable
(1) 3c
Required (see 4.3.3)
Required (see 4.3.3)
Required (see 4.3.3)
4, 5, 6, and 7a
Not applicable
Not applicable
Not applicable
7b
Required
Required
Not required
8
Required
Not required
Not required
9
Not applicable
Not applicable
Required, IR1 and VF2
Required, TA = +110°C;
Required, TA = +110°C; VRWM =
(2) 10
Not applicable
VRWM = 40 V(pk); IO = 0,
40 V(pk); IO = 0, half sine wave, f
half sine wave, f = 60 Hz
= 60 Hz
Required, ĆIR1 ≤ 100
11
Not applicable
Required, IR1 and VFM2
percent of initial reading or
2 µA whichever is greater.
ĆVFM2 ≤ ± 50 mV dc.
12
Required, See 4.3.2
Required, See 4.3.2, t = 48 hours Not applicable
13
Required, Subgroup 2 of
Required, Subgroup 2 of table I
Not applicable
table I herein; ĆIR1 ≤ 100
herein; ĆIR1 ≤ 100 percent of initial
reading or 2 µA whichever is
percent of initial reading or
2 µA whichever is greater;
greater; VFM2 ≤ ± 50 mV dc.
VFM2 ≤ ± 50 mV dc.
14a
Not applicable
Not applicable
Not applicable
14b
Optional (3)
Optional (3)
Not required
15 and 16
Required
Not required
Not required
(1) Thermal impedance shall be performed any time after sealing provided temperature cycling is performed in
accordance with table E-IV of MIL-PRF-19500, screen 3 prior to this thermal test.
(2) Junction temperature (TJ) is not to exceed 115°C at VRWM. TJ is affected by the device mounting thermal
resistance when parasitic power is generated by the temperature dependent leakage current. Until this leakage
becomes significant near thermal runaway, TJ remains approximately equal to TA or TJ for IO = 0.
(3) In accordance with MIL-PRF-19500.
