MILPRF19500/624E
TABLE I. Group A inspection.
Limit
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 1
Visual and mechanical
examination
2071
Subgroup 2
Thermal impedance 2/
3131
See 4.3.1
°C/W
ZθJX
Bias condition D, IC = 100 mA dc;
VCEO(sus)
Breakdown voltage
3011
100
V dc
collector to emitter
pulsed (see 4.5.1)
Bias condition D; VCE = 50 V dc
ICEO
Collector to emitter
3041
1.0
mA
cutoff current
Bias condition D, VEB = 5 V dc
IEBO
Emitter to base
3061
2.0
mA
cutoff current
Bias condition A, VBE = 1.5 V dc
ICEX1
Collector to emitter
3041
0.01
mA dc
VCE = 100 V dc
cutoff current
Test condition A; IC = 12 A dc
VBE(sat)
Base to emitter
3066
4.0
V dc
saturated voltage
IC = 12 A dc; IB = 120 mA dc;
VCE(sat)
Saturation voltage;
3071
3.0
V dc
collector to emitter
pulsed (see 4.5.1)
VCE = 3.0 V dc, IC = 6.0 A dc;
hFE1
Forward-current transfer ratio
3076
1,000
18,000
pulsed (see 4.5.1)
VCE = 3.0 V dc, IC = 12 A dc,
hFE2
Forward-current transfer ratio
3076
150
pulsed (see 4.5.1)
Subgroup 3
TA = +150°C
High temperature operation:
Bias condition A, VBE = 1.5 V dc
ICEX2
Collector to emitter
3041
5.0
mA dc
VCE = 100 V dc
cutoff current
TA = 55°C
Low temperature operation:
VCE = 3.0 V dc, IC = 6.0 A dc,
hFE3
Forward-current
3076
300
transfer ratio
pulsed (see 4.5.1)
