MILPRF19500/624E
TABLE I. Group A inspection Continued.
Limit
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 4
Pulse response
µs
Turn-on time
See figure 4
ton
2.0
µs
Turn-off time
See figure 4
toff
10
VCE = 3.0 V dc; IC = 5.0 A dc;
Magnitude of small-signal
3306
|hfe|
10
250
short-circuit forward-
f = 1 MHz
current transfer ratio
Subgroup 5
TC = +25°C; t ≥ 1 s; 1 cycle;
Safe operating area
3051
(continuous dc)
(see figure 5)
VCE = 8.3 V dc; IC = 12.0 A dc
Test 1
VCE = 30 V dc; IC = 3.3 A dc
Test 2
VCE = 90 V dc; IC = 150 mA dc
Test 3
Safe operating area
3053
Load condition B (clamped inductive
load); TA = +25°C; tr + tf ≤ 1.0 µs;
(switching, clamped
duty cycle ≤ 2 percent; tp = 1 ms;
inductive)
(vary to obtain IC); Rs = 0.10 Ω;
RBB1 = 80 Ω; VBB1 =16 V dc;
RBB2 = 100 Ω; VBB2 = 1.5 V dc;
IC =12 A dc; VCC = 20 V dc;
RL ≤ 2 Ω; L = 10 mH;
(Stancor C-2688 or equivalent)
clamp voltage = 100 +0, 5 V dc;
Device fails if clamp voltage not
reached
Electrical measurements
See subgroup 2 of this table
Subgroups 6 and 7
Not applicable
1/
For sampling plan see MILPRF19500.
2/
This test required for the following end-point measurements only:
Group B, subgroups 3, 4, and 5 (JANS).
Group B, subgroups 2 and 3 (JAN, JANTX, and JANTXV).
Group C, subgroup 2 and 6.
Group E, subgroup 1.
