INCH-POUND
The documentation and process conversion measures
necessary to comply with this document shall be
MIL-PRF-19500/323N
completed by 24 August 2013.
24 May 2013
SUPERSEDING
MIL-PRF-19500/323M
28 October 2011
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, SWITCHING,
TYPES 2N3250A, 2N3251A, 2N3250AUB, 2N3251AUB,
JAN, JANTX, JANTXV, JANTXVM, JANTXVD, JANTXVP, JANTXVL, JANTXVR, JANTXVF, JANTXVG, JANTXVH,
JANS, JANSM, JANSD, JANSP, JANSL, JANSR, JANSF, JANSG, JANSH, JANHC, JANHCM, JANHCD, JANHCP,
JANHCL, JANHCR, JANHCF, JANHCG, JANHCH, JANKC, JANKCM, JANKCD, JANKCP, JANKCL, JANKCR,
JANKCF, JANKCG, AND JANKCH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP silicon switching transistors. Four
levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product
assurance are provided for die. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the
device prefix to identify devices which have passed RHA requirements.
1.3 Maximum ratings, unless otherwise specified, TC = + 25°C.
Type
PT (1)
PT (1)
PT (1)
VCBO
VCEO
VEBO
IC
TJ and
RθJ(PCB)
RθJC
RθJSP
TC = +25°C
TSP = +25°C
(2)
(2)
(2)
TPCB =
TSTG
+25°C
°C/W
°C/W
°C/W
°C
mW
mW
mW
V dc
V dc
V dc
mA dc
2N3250A
360
360
N/A
60
60
5.0
200
325
150
N/A
-65 to
2N3251A
360
360
N/A
60
60
5.0
200
325
150
N/A
+200
2N3250AUB
360
N/A
360
60
60
5.0
200
325
N/A
95
2N3251AUB
360
N/A
360
60
60
5.0
200
325
N/A
95
(1) For derating, see figures 4, 5, and 6.
(2) For thermal impedance curves, see figures 7, 8, and 9.
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
Columbus, ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil.
Since contact information can change, you may want to verify the currency of this address information using the
ASSIST Online database at https://assist.dla.mil .
AMSC N/A
FSC 5961
