MIL-PRF-19500-350 Semiconductor Device, Transistor, Pnp, Silicon, Low Power Types 2N3867, 2N3867S, 2N3867U4, 2N3868, 2N3868S, And 2N3868U4, Jan, Jantx, Jantxv, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, Jansh, Janhcb, Jankcb, Jankcbm, Jankcbd, Jankcbp, Jankcbl, Jankcbr, Jankcbf, Jankcbg, And JankcbhThis specification covers the performance requirements for PNP, silicon, switching transistor. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type. Provisions for radiation hardness assurance \(RHA\) to eight radiation levels is provided for JANTXV, JANS, JANHC, and JANKC product assurance levels. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15

MIL-PRF-19500/350L

1.4 Primary electrical characteristics.

hFE

Cobo

|hfe|

VCE(sat)2

IE = 0

IC = 100 mA dc

IC = 1.5 A dc

VCB = 10 V dc VCE = 5 V dc

IB = 150 mA dc IB = 150 mA dc

IC = 3.0 A dc

IC = 1.5 A dc

100 kHz ≤ f ≤ 1 f = 20 MHz

VCE = 5 V dc

VCE = 2 V dc

MHz

ton

toff

2N3867 2N3868 2N3867

2N3868

2N3867S 2N3868S 2N3867S 2N3968S

2N3867U4 2N3868U4 2N3867U4 2N3968U4

ns max ns max

V dc

Min

Max

200

150

120

100

600

0.75

2. APPLICABLE DOCUMENTS

2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This

section does not include documents cited in other sections of this specification or recommended for additional

information or as examples. While every effort has been made to ensure the completeness of this list, document

users are cautioned that they must meet all specified requirements documents cited in sections 3, 4, or 5 of this

specification, whether or not they are listed.

2.2 Government documents.

2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a

part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are

those cited in the solicitation or contract.

DEPARTMENT OF DEFENSE SPECIFICATION

MIL-PRF-19500 - Semiconductor Devices, General Specification for.

DEPARTMENT OF DEFENSE STANDARD

MIL-STD-750 - Test Methods for Semiconductor Devices.

* (Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch or

https://assist.daps.dla.mil or from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D,

Philadelphia, PA 19111-5094.)

* 2.3 Order of precedence Unless otherwise noted herein or in the contract, in the event of a conflict between the

text of this document and the references cited herein the text of this document takes precedence. Nothing in this

document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.
