MIL-PRF-19500/382J

5. PACKAGING

5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or

order (see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these

personnel need to contact the responsible packaging activity to ascertain packaging requirements. Packaging

requirements are maintained by the Inventory Control Point's packaging activities within the Military Service or

Defense Agency, or within the Military Service's system commands. Packaging data retrieval is available from the

managing Military Department's or Defense Agency's automated packaging files, CD-ROM products, or by contacting

the responsible packaging activity.

6. NOTES

(This section contains information of a general or explanatory nature that may be helpful, but is not mandatory.

The notes specified in MIL-PRF-19500 are applicable to this specification.)

* 6.1 Intended use. Semiconductors conforming to this specification are intended for original equipment design

applications and logistic support of existing equipment.

6.2 Acquisition requirements. Acquisition documents should specify the following:

a. Title, number, and date of this specification.

b. Packaging requirements (see 5.1).

c. Lead finish (see 3.4.1).

d. Product assurance level and type designator.

e. For acquisition of RHA designed devices, table II, subgroup 1 testing of group D is optional. If subgroup 1

testing is desired, it should be specified in the contract.

* 6.3 Qualification. With respect to products requiring qualification, awards will be made only for products which

are, at the time of award of contract, qualified for inclusion in Qualified Manufacturers List (QML 19500) whether or

not such products have actually been so listed by that date. The attention of the contractors is called to these

requirements, and manufacturers are urged to arrange to have the products that they propose to offer to the Federal

Government tested for qualification in order that they may be eligible to be awarded contracts or orders for the

products covered by this specification. Information pertaining to qualification of products may be obtained from

DLA Land and Maritime, ATTN: VQE, P.O. Box 3990, Columbus, OH 43218-3990 or e-mail vqe.chief@dla.mil. An

online listing of products qualified to this specification may be found in the Qualified Products Database (QPD) at

6.4 Suppliers of JANHC and JANKC die. The qualified JANHC and JANKC suppliers with the applicable letter

version (example JANHCA2N2945) will be identified on the QML.

Die ordering information

Manufacturer

34156

2N2944A

JANHCA2N2944A, JANKCA2N2944A

2N2945A

JANHCA2N2945A, JANKCA2N2945A

2N2946A

JANHCA2N2946A, JANKCA2N2946A
