INCH-POUND
The documentation and process conversion measures
necessary to comply with this document shall be
MIL-PRF-19500/398K
completed by 18 September 2011.
18 June 2011
SUPERSEDING
MIL-PRF-19500/398J
26 January 2010
PERFORMANCE SPECIFICATION SHEET
* SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, HIGH-FREQUENCY,
TYPES 2N3866, 2N3866A, 2N3866UB, 2N3866AUB, JAN, JANTX, JANTXV, JANS, JANHC, JANKC, JANSM,
JANSD, JANSP, JANSL, JANSR, JANSF, JANSG, JANSH, JANHCM, JANHCD, JANHCP, JANHCL, JANHCR,
JANHCF, JANHCG, JANHCH, JANKCM, JANKCD, JANKCP, JANKCL, JANKCR, JANKCF, JANKCG, AND JANKCH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
* 1.1 Scope. This specification covers the performance requirements for NPN silicon, VHF-UHF amplifier transistor.
Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of
product assurance are provided for die. Radiation hardness assurance (RHA) level designators "M", "D", "P", "L",
"R", "F", "G", and "H" are appended to the device prefix to identify devices which have passed RHA requirements.
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
Types
PT (1)
PT
TJ and
RθJC
RθJA
VCBO
VCEO
VEBO
IC
TA = (2)
TC = (3)
TSTG
°C
°C/W
°C/W
W
W
V dc
V dc
V dc
A dc
2N3866, 2N3866A
1.0
2.9
60
30
3.5
0.4
-65 to
60
175
+200
2N3866UB,
0.5
60
30
3.5
0.4
-65 to
325
2N3866AUB
+200
(1) Derate linearly 5.71 mW/°C (2N3866, 2N3866A) and 3.08 mW/°C (2N3866UB, 2N3866AUB) above
TA ≥ +25°C.
(2) TA = room ambient as defined in the general requirements of MIL-PRF-19500.
(3) PT = 2.9 W at TC = +25°C, derate at 16.6 mW/°C above TC > +25°C.
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or or emailed to Semiconductor@dla.mil. Since
contact information can change, you may want to verify the currency of this address information using the
ASSIST Online database at https://assist.daps.dla.mil .
AMSC N/A
FSC 5961
