MIL-PRF-19500-398 Semiconductor Device, Transistor, Npn, Silicon, High-Frequency, Types 2N3866, 2N3866A, 2N3866Ub, 2N3866Aub, Jan, Jantx, Jantxv, Jans, Janhc, Jankc, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, Jansh, Janhcm, Janhcd, Janhcp, Janhcl, Janhcr, Janhcf, Janhcg, Janhch, Jankcm, Jankcd, Jankcp, Jankcl, Jankcr, Jankcf, Jankcg, And JankchThis specification covers the performance requirements for NPN silicon, VHF-UHF amplifier transistor. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for die. Radiation hardness assurance \(RHA\) level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-PRF-19500/398K
UB
Dimensions
Dimensions
Note
Ltr.
Note
Ltr.
Inches
Millimeters
Inches
Millimeters
Min
Max
Min
Max
Min
Max
Min
Max
BH
.046
.056
1.17
1.42
LS1
.035
.040
0.89
1.02
BL
.115
.128
2.92
3.25
LS2
.071
.079
1.80
2.01
BW
.085
.108
2.16
2.74
LW
.016
.024
0.41
0.61
CL
.128
3.25
r
.008
0.20
CW
.108
2.74
r1
.012
0.31
LL1
.022
.038
0.56
0.97
r2
.022
0.56
LL2
.017
.035
0.43
0.89
NOTES:
1.
Dimensions are in inches.
2.
Millimeters are given for general information only.
3.
Hatched areas on package denote metallized areas.
4.
Lid material: Kovar.
5.
Pad 1 = Base, Pad 2 = Emitter, Pad 3 = Collector, Pad 4 = Shielding connected to the lid.
In accordance with ASME Y14.5M, diameters are equivalent to Φx symbology.
*
6.
* FIGURE 2. Physical dimensions, surface mount (UB).
4
