MIL-PRF-19500-478 Semiconductor Device, Diode, Silicon, Power Rectifier, Fast Recovery, Types 1N5812, 1N5814, 1N5816, And R Versions, Jan, Jantx, Jantxv, Janhc, Jankc, And JansThis specification covers the performance requirements for silicon, fast recovery power rectifier diodes. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two product assurance levels are provided for die.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


. . . .
MIL-PRF-19500/478K
* TABLE II. Group E inspection (all quality levels) for qualification and requalification only.
Inspection
Sampling
plan
Method
Conditions
Subgroup 1
45 devices
c=0
Thermal shock (glass
1056
0°C to +100°C, 100 cycles.
strain)
*
Electrical measurements
See table I, subgroup 2 and table III, step 1.
*
Subgroup 2
45 devices
c=0
Steady-state dc blocking
1038
Test condition A, except in accordance with 4.3.3; 1,000
life
hours.
*
Electrical measurements
See table I, subgroup 2.
Subgroup 3
Not applicable
Subgroup 4
Thermal impedance
3101 or
curves
4081
Subgroup 5
Not applicable
14
