MIL�PRF�19500/586L

TABLE II. Group E inspection (all quality levels) for qualification and re-qualification.

Inspection

Sampling

plan

Method

Conditions

45 devices

Subgroup 1

c=0

100 cycles 0�C to 100�C.

Thermal shock

1056

500 cycles -65�C to 150�C.

Temperature cycling

1051

Hermetic seal

1071

Test condition E.

Electrical measurement

See table I, subgroup 2.

45 devices

Subgroup 2

c=0

10,000 cycles, If = 1 A dc, Ton = Toff = 1 minute.

Intermittent operating life

1036

Electrical measurement

See table I, subgroup 2.

Subgroup 4

Thermal impedance curves

Sample size

N/A

Subgroup 5

Not applicable

Subgroup 6

11 devices

ESD

1020

Subgroup 8

45 devices

c=0

Resistance to glass cracking

1057

Test condition B. Test to destruction or 25 cycles max

whichever comes first.
