MIL-PRF-19500/587E
TABLE III. Groups A, B, C, and E delta measurements. 1/ 2/ 3/ 4/
Step
Inspection
MIL-STD-750
Symbol
Limits
Unit
Method
Conditions
Min
Max
ĆIR1 5/
1.
Reverse current
4016
DC method
100 percent of initial value or
±.010 µA dc, whichever is
1N6661, US
greater.
VR = 225 V dc
1N6662, US
VR = 400 V dc
1N6663, US
VR = 600 V dc
±25 mV dc change from
ĆVF1 5/
2.
Forward voltage
4011
IF = 400 mA dc
previously measured value.
(pulsed) 2 percent duty
cycle max; 8.3 ms max
pulse width
The delta measurements for appendix E, table E-VIA (JANS) of MIL-PRF-19500 are as follows:
1/
a. Subgroup 4, see table III herein, steps 1 and 2.
b. Subgroup 5, see table III herein, steps 1 and 2.
The delta measurements for appendix E, table E-VIB (JANTX and JANTXV) of MIL-PRF-19500 are as follows:
2/
a. Subgroup 3, see table III herein, steps 1 and 2.
b. Subgroup 6, see table III herein, step 1.
The delta measurements for appendix E, table E-VII of MIL-PRF-19500 are as follows: Subgroup 6,
3/
see table III herein, steps 1 and 2 (JANS); step 1 (JANTX and JANTXV).
The delta measurements for appendix E, table E-IX of MIL-PRF-19500 are as follows; subgroup 2,
4/
see table III herein, step 1.
Devices which exceed the table I limits for this test shall not be accepted.
5/
14
