MIL�PRF�19500/597G

TABLE II. Group E inspection (all quality levels) for qualification or re-qualification only. 1/

MIL�STD�750

Inspection

Sample plan

Method

Conditions

45 devices

Subgroup 1

c=0

Temperature cycling

1051

(air to air)

Hermetic seal

1071

Fine leak

Gross leak

Electrical measurements

See table I, subgroup 2.

45 devices

Subgroup 2 2/

c=0

Steady-state reverse bias

1042

Condition A, 1,000 hours.

Electrical measurements

See table I, subgroup 2.

Steady-state gate bias

1042

Condition B, 1,000 hours

Electrical measurements

See table I, subgroup 2.

Subgroup 4

Sample size N/A

Thermal impedance curves

See MIL�PRF�19500.

Subgroup 5

Not applicable

Subgroup 6

11 devices

Electrostatic discharge

1020

sensitivity

Subgroup 11

22 devices

c=0

Test procedure for measuring

3476

Test conditions shall be derived by the

dv/dt during reverse recovery

manufacturer.

of power MOSFET transistors

JANHC and JANKC devices are qualified in accordance with appendix G of MIL�PRF�19500.

A separate sample for each test may be selected.
