MIL-PRF-19500-597 Semiconductor Device, Transistors, Quad, Field Effect, N-Channel, Silicon, Type 2N7334, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for quad N-channel, enhancement-mode, MOSFET, power transistor with avalanche energy ratings \(EAS and EAR\) and maximum avalanche current \(IAR\). Four levels of product assurance are provided for each hermetic encapsulated device type as specified in MIL?√PRF?√19500. Two levels of product assurance are provided for each unencapsulated device type \(die\) as specified in MIL?√PRF?√19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


MIL­PRF­19500/597G
Dimensions
Dimensions
Symbol
Inches
Millimeters
Notes
Symbol
Inches
Millimeters
Notes
Min
Max
Min
Max
Min
Max
Min
Max
BH
.105
.175
2.67
4.45
4
LS
.100 TP
2.54 TP
7
LS1
BL
.690
.770
17.53
19.56
.300 TP
7.62 TP
7
BW
.280
.310
7.11
7.87
LW
.015
.021
0.381
0.533
6
BW1
LW1
.290
.325
7.37
8.26
5
.038
.060
0.97
1.52
LH
.025
.055
0.64
1.40
4, 6
R
.010
0.25
LL
.125
.175
3.18
4.45
4
S
.030
.095
0.76
2.41
α
0°
15°
0°
15°
LT
.008
.012
0.203
0.305
8
NOTES:
1.  Dimensions are in inches. Millimeters are for general information only.
2.  Pin-out: G = gate, S = source, D = drain, and NC = not connected.
3.  Index area: A notch or a pin 1 identification mark shall be located adjacent to pin 1. The manufacturer's
identification shall not be used as a pin 1 identification mark.
4.  This dimension shall be measured with the device seated in seating plane gauge JEDEC Outline No. GS­3.
5.  Lead center when α is 0°. BW1 shall be measured at the centerline of the leads.
6.  Outlines on which the seating plane is coincident with the base plane (LH = 0), terminals lead standoffs are
not required, and LW1 may equal LW along any part of the lead above the seating/base plane.
7.  Leads within .005 inch (0.13 mm) radius of True Position (TP) at gauge plane with maximum material
condition and unit installed. Twelve spaces.
8.  α applies to spread leads prior to installation.
9.  Dimensioning and tolerancing in accordance with ASME Y14.5.
FIGURE 1. Physical dimensions and configuration (MO­036AB).
3
