MIL�PRF�19500/598C

TABLE III. Group E inspection (all quality levels) for qualification or re-qualification only.

MIL�STD�750

Inspection

Sample plan

Method

Conditions

45 devices

Subgroup 1

c=0

Temperature cycling

1051

Condition G, 500 cycles.

(air to air)

Hermetic seal

1071

Fine leak

Gross leak

See table I, subgroup 2 and table II, step 7.

End-point electrical

measurements

Subgroup 2 1/

45 devices

c=0

Steady-state reverse bias

1042

Condition A, 1,000 hours.

Electrical measurements

See table I, subgroup 2.

Steady-state gate bias

1042

Condition B, 1,000 hours.

End-point electrical

See table I, subgroup 2 and table II, step 7.

measurements

Subgroup 4

Sample size N/A

Thermal impedance curves

See MIL�PRF�19500.

Subgroup 6

11 devices

Electrostatic discharge

1020

sensitivity

Subgroup 11

3476

22 devices

c=0

Test procedure for measuring

dv/dt during reverse recovery

of power MOSFET transistors

A separate sample for each test may be selected pulled.
