The documentation and process conversion measures
INCH-POUND
necessary to comply with this document shall be
completed by 18 February 2014.
MIL-PRF-19500/613E
18 December 2013
SUPERSEDING
MIL-PRF-19500/613D
21 September 2011
PERFORMANCE SPECIFICATION SHEET
* SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, POWER,
TYPE 2N7373, JAN, JANTX, JANTXV, JANS AND JANSM, D, P, L, R, F, G, AND H
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN, silicon, power transistors for use in
high-speed power switching applications. Four levels of product assurance are provided as specified in
MIL-PRF-19500. Provisions for radiation hardness assurance (RHA) to eight radiation levels is provided for JANS
product assurance level. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device
prefix to identify devices, which have passed RHA requirements.
1.2 Physical dimensions. See figure 1 (TO-254AA).
1.3 Maximum ratings. Unless otherwise specified, TC = +25°C.
RθJA
RθJC
TJ and TSTG
PT (1)
PT (2)
VCBO VCEO VEBO
IC
IC
Type
TA = +25°C TC = +25°C
(3)
°C/W
°C/W
°C
W
W
V dc
V dc
V dc
A dc
A dc
2N7373
4
58
43.75
3
100
80
5.0
5.0
10
-65 to +200
Derate linearly 22.8 mW/°C for TA > +25°C.
(1)
Derate linearly 331 mW/°C for TC > +25°C.
(2)
This value applies for PW ≤ 8.3 ms, duty cycle ≤ 1percent.
(3)
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST Online
database at https://assist.dla.mil.
AMSC N/A
FSC 5961
