MIL-PRF-19500/614J
1.3 Maximum ratings. continued
(1) Derate linearly by 0.6 W/°C for TC > +25°C.
(2) See figure 2, thermal impedance curves.
(3) The following formula derives the maximum theoretical ID limit. ID is limited by package and device construction.
TJM - TC
ID =
( RθJC
) x ( RDS ( on ) at TJM
)
(4) See figure 3, maximum drain current graph.
(5) IDM = 4 X ID1 as calculated in note (3).
1.4 Primary electrical characteristics. Unless otherwise specified, TC = +25°C.
IDSS max
Max rDS(on)1 (1)
Min V(BR)DSS
VGS(th)1
VGS = 0
VGS = 12 V; ID = ID2
VDS ≥ VGS
Type
VGS = 0
VDS = 80 percent
TJ = +25°C
TJ = +150°C
ID = 1.0 mA dc
of rated VDS
ID = 1.0 mA dc
µA dc
Ω
Ω
V dc
V dc
Min
Max
2N7380
100
2.0
4.0
25
0.18
0.33
2N7381
200
2.0
4.0
25
0.40
0.84
(1) Pulsed (see 4.5.1).
2. APPLICABLE DOCUMENTS
* 2.1 General. The documents listed in this section are specified in sections 3 or 4 of this specification. This section
does not include documents cited in other sections of this specification or recommended for additional information or
as examples. While every effort has been made to ensure the completeness of this list, document users are
cautioned that they must meet all specified requirements of documents cited in sections 3 or 4 of this specification,
whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
-
Semiconductor Devices, General Specification for.
DEPARTMENT OF DEFENSE STANDARDS
-
Test Methods for Semiconductor Devices.
* (Copies of these documents are available online at https://quicksearch.dla.mil/.
2.3 Order of precedence. Unless otherwise noted herein or in the contract, in the event of a conflict between the
text of this document and the references cited herein, the text of this document takes precedence. Nothing in this
document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.
