INCH-POUND
The documentation and process conversion measures
necessary to comply with this document shall be
MIL-PRF-19500/406L
completed by 3 June 2014.
3 March 2014
SUPERSEDING
MIL-PRF-19500/406K
9 April 2012
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICES, DIODE, SILICON, VOLTAGE REGULATOR,
TYPES 1N4460, 1N4460C, 1N4460D THROUGH 1N4496, 1N4496C, 1N4496D, AND 1N6485, 1N6485C, 1N6485D
THROUGH 1N6491, 1N6491C, 1N6491D, 1N4460US, 1N4460CUS, 1N4460DUS THROUGH 1N4496US,
1N4496CUS, 1N4496DUS, AND 1N6485US, 1N6485CUS, 1N6485DUS THROUGH 1N6491US, 1N6491CUS,
1N6491DUS, 1N4460UM THROUGH 1N4496UM, PLUS C AND D TOLERANCE SUFFIX; JAN, JANTX, JANTXV,
AND JANS
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MILPRF19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for micro-miniature 1.5 watt silicon, low
leakage, voltage regulator diodes with tolerances of 5 percent, 2 percent, and 1 percent. Four levels of product
assurance are provided for each encapsulated device type as specified in MILPRF19500.
1.2 Physical dimensions. See figure 1 (DO-41), figure 2 (surface mount), and figure 3 (UM surface mount).
1.3 Maximum ratings. TSTG = TJ(max) = -65°C to +175°C. Maximum ratings are as shown in maximum and primary
test ratings (see 3.11) herein and as follows:
PT at
RθJL at
L = .375 inch
TL = +112ºC
PT
PT(PCB1)
PT(PCB2)
PT
TA = +55ºC At TSP = +25°C
L = .375 inch
(9.52 mm)
at TEC =
at TA =
(9.53 mm)
+145ºC
+55ºC
0.6 W
1.5 W
1.5 W
1.5 W
1.5 W
42ºC/W
(1)
(2)
(3)
(4)
(5)
(6)
Barometric pressure reduced
RθJEC
RθJSP
RθJA(PCB1)
RθJA(PCB2)
(high altitude operation)
56°C/W
20ºC/W
200ºC/W
80ºC/W
8 mm Hg
(7)
(3)
(4)
(8)
(2)
Derate: See figure 5 herein.
(3)
(4)
(5)
Derate: See figure 8 herein.
(6)
(7)
(8)
See figure 13 herein.
Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil . Since contact
information can change, you may want to verify the currency of this address information using the ASSIST Online
database at https://assist.dla.mil .
AMSC N/A
FSC 5961
