The documentation and process conversion measures
INCH-POUND
necessary to comply with this document shall be
completed by 5 August 2014.
MIL-PRF-19500/411R
5 May 2014
SUPERSEDING
MIL-PRF-19500/411P
15 August 2013
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, POWER RECTIFIER, FAST RECOVERY,
1N5415 THROUGH 1N5420, 1N5415US THROUGH 1N5420US,
JAN, JANTX, JANTXV, JANS, JANTXVM, JANTXVD, JANTXVR,
JANTXVH, JANSM, JANSD, JANSR, AND JANSH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for silicon rectifier diodes. Four levels of
product assurance are provided for each device type as specified in MIL-PRF-19500. Provision for radiation
hardness assurance (RHA) to four radiation test levels is provided for JANTXV and JANS product assurance levels.
RHA level designators "M", "D", "R", and "H" are appended to the device prefix to identify devices which have passed
RHA requirements.
1.3 Maximum ratings. Unless otherwise specified, TA = 25°C.
Col. 1
Col. 2
Col. 3
Col. 4
Col. 5
Col. 6
Col.
Col.
Col. 9
Col. 10
Col.
7
8
11
Types
VBR
VRWM
IO (1)
IO
trr
TSTG
RθJL
RθJEC
IFSM
RθJX
and
at
at
(3)
TJ
L = .375 in.
L=0
TA =
TA =
IO = 2 A dc
TA = 55°C
55°C
100°C
(9.53 mm)
for US
(4)
versions
(2) (3)
(2) (3)
tp = 8.3 ms
(5)
°C
°C/W
°C/W
°C/W
V dc
V (pk)
A dc
A dc
A (pk)
ns
1N5415, US
50
50
3
2
80
150
-65
22
6.5
43
1N5416, US
100
100
3
2
80
150
to
22
6.5
43
1N5417, US
200
200
3
2
80
150
+175
22
6.5
43
1N5418, US
400
400
3
2
80
150
22
6.5
43
1N5419, US
500
500
3
2
80
250
22
6.5
43
1N5420, US
600
600
3
2
80
400
22
6.5
43
See notes on next page.
Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.dla.mil.
AMSC N/A
FSC 5961
