MIL-PRF-19500/411R

TABLE IV. Delta measurements. 1/ 2/ 3/ 4/ 5/

Step

Inspection

Symbol

Limit

Unit

Method

Conditions

Min

Max

DC method

Reverse current

4016

100 percent of initial

ĆIR

VR = rated (see col. 2 of

value or 250 nA dc,

whichever is greater.

Devices which exceed the group A limits for this test shall not be accepted.

The delta measurements for group B inspection in appendix E, table E-VIA (JANS) of MIL-PRF-19500 are as

follows:

a. Subgroup 4, see table IV herein, step 1.

b. Subgroup 5, see table IV herein, step 1.

The delta measurements for group B inspection in appendix E, table E-VIB (JAN, JANTX, and JANTXV) of

MIL-PRF-19500 are as follows:

a. Subgroup 3, see table IV herein, step 1.

b. Subgroup 6, see table IV herein, step 1.

The delta measurements for group C inspection in appendix E, table E-VII (all quality levels) of

MIL-PRF-19500 are as follows:

a. Subgroup 2, see table IV herein, step 1.

b. Subgroup 6, see table IV herein, step 1.

The delta measurements for group E inspection in appendix E, table E-IX of MIL-PRF-19500 are as

follows:

a. Subgroup 1, see table IV herein, step 1.

b. Subgroup 2, see table IV herein, step 1.

c. Subgroup 10, see table IV herein, step 1.
