MIL-PRF-19500-411 Semiconductor Device, Diode, Silicon, Power Rectifier, Fast Recovery, 1N5415 Through 1N5420, 1N5415Us Through 1N5420Us, Jan, Jantx, Jantxv, Jans, Jantxvm, Jantxvd, Jantxvr, Jantxvh, Jansm, Jansd, Jansr, And JanshThis specification covers the performance requirements for silicon rectifier diodes. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Provision for radiation hardness assurance \(RHA\) to four radiation test levels is provided for JANTXV and JANS product assurance levels. RHA level designators "M", "D", "R", and "H" are appended to the device prefix to identify devices which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


. . . . . .
MIL-PRF-19500/411R
TABLE I. Group A inspection - Continued.
Inspection 1/
Symbol
Limits
Unit
Method
Condition
Min
Max
Subgroup 4
Reverse recovery time
4031
Condition B1
trr
1N5415, 1N5415US
150
ns
1N5416, 1N5416US
150
ns
1N5417, 1N5417US
150
ns
1N5418, 1N5418US
150
ns
1N5419, 1N5419US
250
ns
1N5420, 1N5420US
400
ns
Capacitance
4001
C
VR = 4 V dc; 100 Khz ≤ f ≤ 1
Mhz
1N5415, 1N5415US
550
pF
1N5416, 1N5416US
430
pF
1N5417, 1N5417US
250
pF
1N5418, 1N5418US
165
pF
1N5419, 1N5419US
140
pF
1N5420, 1N5420US
120
pF
See 4.5.2, n = 116, c = 0
Scope display evaluation
4023
Subgroup 5
Not applicable
Subgroup 6
Forward surge
4066
Condition A, IFSM = rated (see
*
col. 6 of 1.3); ten surges of 8.3
ms each at 1 minute intervals,
superimposed on IO = 2 A dc,
VRWM = rated VRWM (see col. 3
of 1.3).
Electrical measurement
See table IV, step 1.
Subgroup 7
Not applicable
For sampling plan, see MIL-PRF-19500.
1/
2/
This test required for the following end-point measurements only:
Group B, subgroups 3, 4, and 5 (JANS).
Group B, subgroups 2 and 3 (JAN, JANTX, and JANTXV).
Group C, subgroup 2 and 6.
Group E, subgroup 1.
10
