MIL-PRF-19500/427P
shall be completed by 20 September 2013.
20 June 2013
SUPERSEDING
MIL-PRF-19500/427N
9 April 2011
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, POWER RECTIFIER,
TYPES 1N5614, 1N5616, 1N5618, 1N5620, 1N5622, 1N5614US, 1N5616US,
1N5618US, 1N5620US, 1N5622US, JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for silicon, hermetically sealed power rectifier
diodes. Four levels of product assurance are provided for each encapsulated device as specified in
MIL-PRF-19500. Two levels of product assurance are provided each unencapsulated device type.
1.2 Physical dimensions. See figure 1 (axial lead), figure 2 (surface mount), and figure 3 (JANHC and JANKC).
1.3 Maximum ratings. Unless otherwise specified TA = 25°C.
1.3.1 Ratings applicable to all Part or Identifying Numbers (PIN). TSTG = TJ(max) = -65°C to +175°C.
1.3.2 Ratings applicable to individual types.
Col. 1
Col. 2
Col. 3
Col. 4
Col. 5
Col. 6
Col. 7
Col. 8
Col. 9
Types
trr
IO1
IFSM
IO2
VRWM
RθJL
RθJEC
RθJX
TA = +55°C
TA =
TA =
at L = .375
(4)
(4)
+55°C
+100°C
(1)
inch (9.53
IF = 750 mA
(2)
(3)
mm)
tp = 8.3 ms
(4)
µs
°C/W
°C/W
°C/W
A
mA
V
A
1
750
200
30
1N5614, US
2
36
13
133
1
750
400
30
1N5616, US
2
36
13
133
1
750
600
30
1N5618, US
2
36
13
133
1
750
800
30
1N5620, US
2
36
13
133
1
750
1,000
30
1N5622, US
2
36
13
133
See notes on next page.
