MILPRF19500/427P
* TABLE III. Groups B and C delta measurements. 1/ 2/ 3/ 4/
Limits
Step
Inspection
Symbol
Unit
Method
Conditions
Min
Max
For JAN, JANTX, and
JANTXV ≤ 250 nA or
ĆIR1 5/
1.
Reverse current
4016
DC method
leakage change
100 percent,
whichever is greater,
For JANS ≤ 100 nA
or 100 percent,
whichever is greater.
±50 mV maximum
ĆVF2 5/
2.
Forward voltage
4011
IF = 3 A;
change
change from previous
pulsed (see 4.5.1)
measured value.
1/
The delta measurements for group B inspections in table VIA (JANS) of MIL-PRF-19500, appendix E, are as
follows:
a. Subgroup 3, perform step 2.
b. Subgroup 4, perform step 2.
c. Subgroup 5, perform steps 1 and 2.
The delta measurements for group B inspections in table VIB (JAN, JANTX and JANTXV) of MIL-PRF-19500,
2/
appendix E are as follows:
a. Subgroup 3, perform step 1.
b. Subgroup 6, perform step 1.
The delta measurements for group C inspections in table VII of MIL-PRF-19500, appendix E, are as follows:
3/
a. Subgroup 2, perform steps 1 and 2 (JANS).
b. Subgroup 6, perform steps 1 and 2 (JANS), step 1 (JAN, JANTX, and JANTXV).
4/
The delta measurements for table IX of MIL-PRF-19500, appendix E, are as follows:
a. Subgroup 1, perform steps 1 and 2.
b. Subgroup 2, perform steps 1 and 2.
5/
Devices which exceed the limits of table I herein for this test shall not be accepted.
15
