The documentation and process conversion measures
INCH-POUND
necessary to comply with this document shall be
completed by 15 August 2014.
MIL-PRF-19500/429N
15 May 2014
SUPERSEDING
MIL-PRF-19500/429M
14 October 2013
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, POWER RECTIFIER,
FAST RECOVERY, TYPES 1N5615, 1N5617, 1N5619, 1N5621, 1N5623,
1N5615US, 1N5617US, 1N5619US, 1N5621US, 1N5623US,
JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for silicon, fast recovery power rectifier diodes
that are hermetic glass encapsulated. Four levels of product assurance are provided for each encapsulated device
as specified in MIL-PRF-19500. Two levels of product assurance are provided each unencapsulated device type.
1.2 Physical dimensions. See figure 1 (axial lead), figure 2 surface mount (D-5A), figures 3, and 4 (JANHC and
JANKC).
1.3 Maximum ratings. Unless otherwise specified TC = +25°C.
Col. 1
Col. 2
Col. 3
Col.
Col. 5
Col. 6
Col. 7
Col. 8
Col. 9
Col. 10
4
Types
VRWM
IO
trr
TSTG
IFSM
Barometric
RθJL
RθJEC
RθJX
TJ
(1)
pressure
(2) (3)
TA =
TA =
TA =
(reduced) L = .375
(6)
+55° +100°C
+100°C
(4)
inch
(9.53
C
IO = 750
mm)
mA dc
(5)
VRWM =
rated
tP = 8.3 ms
°C
°C/W
°C/W
°C/W
V(pk)
A dc
mA dc
ns
A(pk)
mmHg
1N5615
200
1
750
150
25
N/A
-65
38
13
115
1N5617
400
1
750
150
25
8
38
13
115
1
1N5619
600
750
250
25
8
to
38
13
115
1
1N5621
800
750
300
25
33
38
13
115
1N5623
1,000
1
750
500
25
33
+175
38
13
115
See notes on next page.
Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.dla.mil/.
AMSC N/A
FSC 5961
