MIL-PRF-19500/444N
shall be completed by 17 July 2014.
17 April 2014
SUPERSEDING
MIL-PRF-19500/444M
19 December 2011
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, SWITCHING, SCHOTTKY, TYPES 1N5711-1, 1N5711UR-1,
1N5711UB, 1N5711UBCA, 1N5711UBD, 1N5711UBCC, 1N5712-1, 1N5712UR-1, 1N5712UB,
1N5712UBCA, 1N5712UBD, 1N5712UBCC, 1N6857-1, 1N6857UR-1, 1N6858-1, AND 1N6858UR-1,
JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for Schottky barrier diodes. Four levels of
product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500. Two levels of
product assurance are provided for each unencapsulated device type.
Unless otherwise specified TA = +25°C.
* 1.3 Maximum ratings.
RθJL
RθJEC
RθJSP
VRWM
IO1
IO2 (1)
TSTG
Type
(UB)
L = .375 inch
(UR)
and TJ
(9.52 mm) (2)
V(pk)
mA dc
mA dc
(leaded)
(UR)
(UB)
-65°C to
1N5711-1
50
33 (3)
5
250
+150°C
1N5711UR-1
50
33 (4)
5
100
1N5711UB
50
33 (4)
5
100
1N5711UBCA
50
33 (4)
5
100
1N5711UBCC
50
33 (4)
5
100
1N5711UBD
50
33 (4)
5
100
1N6858-1
50
75 (5)
10
250
1N6858UR-1
50
75 (6)
10
100
1N5712-1
16
75 (5)
20
250
1N5712UR-1
16
75 (6)
20
100
1N5712UB
16
75 (6)
20
100
1N5712UBCA
16
75 (6)
20
100
1N5712UBCC
16
75 (6)
20
100
1N5712UBD
16
75 (6)
20
100
1N6857-1
16
150 (7)
50
250
1N6857UR-1
16
150 (8)
50
100
See notes on next page.
