MIL-PRF-19500-444 Semiconductor Device, Diode, Silicon, Switching, Schottky, Types 1N5711-1, 1N5711Ur-1, 1N5711Ub, 1N5711Ubca, 1N5711Ubd, 1N5711Ubcc, 1N5712-1, 1N5712Ur-1, 1N5712Ub, 1N5712Ubca, 1N5712Ubd, 1N5712Ubcc, 1N6857-1, 1N6857Ur-1, 1N6858-1, And 1N6858Ur-1, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for Schottky barrier diodes. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-PRF-19500/444N
UB
Dimensions
Dimensions
Symbol
Inches
Millimeters
Symbol
Inches
Millimeters
Min
Max
Min
Max
Min
Max
Min
Max
LS1
BH
.046
.056
1.17
1.42
.035
.040
0.89
1.02
LS2
BL
.115
.128
2.92
3.25
.071
.079
1.81
2.01
BW
.085
.108
2.16
2.74
LW
.016
.024
0.41
0.61
CL
.128
3.25
r
.008
0.20
CW
.108
2.74
r1
.012
0.31
LL1
.022
.038
0.56
0.96
r2
.022
0.56
LL2
.017
.035
0.43
0.89
1N5711UBCA
1N5711UB
1N5712UBCA
1N5712UB
2
1N5711UBCC
1N5711UBD
1N5712UBCC
1N5712UBD
1
NOTES:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Hatched areas on package denote metallized areas.
4. Pad 4 = Shielding connected to the lid.
5. In accordance with ASME Y14.5M, diameters are equivalent to Φx symbology.
FIGURE 3. Physical dimensions, surface mount (UB version).
5
