MIL-PRF-19500/444N
1.3 Maximum ratings Continued.
Maximum IO rating to ensure τCL compliance (< 100 ps).
(1)
(2)
Lead length = .375 inch (9.52 mm).
At TL = +130°C and L = .375 inch, derate IO to 0 at +150°C.
(3)
At TEC and TSP = +140°C, derate IO to 0 at +150°C.
(4)
At TL = +110°C and L = .375 inch, derate IO to 0 at +150°C.
(5)
At TEC and TSP = +130°C, derate IO to 0 at +150°C.
(6)
At TL = +70°C and L = .375 inch, derate IO to 0 at +150°C.
(7)
At TEC and TSP = +110°C, derate IO to 0 at +150°C.
(8)
1.4 Primary electrical characteristics.
τCL
ZθJX
V(BR)1
VF1
VF2
IR1
C
VR = 0, f = 1 MHz
Type (1)
IR =
IF =
IF = 15
VR =
(max)
Vsig = 50 m V(pk)
(max)
10 µA dc
1 mA dc
mA dc
50 V dc
(max)
(max)
(max)
(max)
(min)
°C/W
V dc
V dc
V dc
nA dc
pF
ps
mA
70
0.410
1.0
200
2.0
100
5
1N5711-1
40
70
0.360
0.65
200
4.5
100
10
1N6858-1
40
τCL
ZθJX
V(BR)1
VF1
VF2
IR1
C
VR = 0, f = 1 MHz
Type (1)
IR =
IF =
IF =
VR =
Vsig = 50 mv(pk)
(max)
10 µA dc
1 mA dc
35 mA dc
16 V dc
(max)
(max)
(max)
(max)
(max)
(min)
°C/W
V dc
V dc
V dc
nA dc
pF
ps
mA
20
0.410
1.0
150
2.0
100
20
1N5712-1
40
20
0.350
0.75
150
4.5
100
50
1N6857-1
40
(1) Electrical characteristics are for all package styles.
