INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MILPRF19500/472F
shall be completed by 11 January 2013.
10 October 2012
SUPERSEDING
MILPRF19500/472E
9 October 2007
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, POWER DARLINGTON,
TYPES 2N6350, 2N6351, 2N6352, AND 2N6353, JAN, JANTX, JANTXV, AND JANHC
Inactive for new design after 7 June 1999
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MILPRF19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN silicon power Darlington transistors.
Three levels of product assurance are provided for each encapsulated device type as specified in MILPRF19500.
One level of product assurance is provided for each unencapsulated device type as specified in MILPRF19500.
1.2 Physical dimensions. The device package styles are as follows: 4-pin TO33 in accordance with figure 1 for
device types 2N6350 and 2N6351, 3-pin TO66 in accordance with figure 2 for device types 2N6352 and 2N6353,
and unencapsulated die in accordance with figure 3 for device type JANHC.
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
PT
Types
VEB1
IC
VEB2
VCBO1
IC (1)
IB1
TJ and
RθJC
and VCER
TSTG
Max
TA = +25°C TC = +100°C
°C/W
°C
W
W
V dc
V dc
V dc
A dc
A dc
A dc
2N6350
1.0
(2)
5 (3)
20
12
6
80
5
10
0.5
65 to +200
2N6351
1.0
(2)
5 (3)
20
12
6
150
5
10
0.5
65 to +200
2N6352
2.0
(4)
25 (5)
4.0
12
6
80
5
10
0.5
65 to +200
2N6353
2.0
(4)
25 (5)
4.0
12
6
150
5
10
0.5
65 to +200
Applies for tp ≤ 10 ms, duty cycle ≤ 50 percent.
(1)
Derate linearly 5.72 mW/°C for TA > +25°C.
(2)
Derate linearly 50 mW/°C for TC > +100°C.
(3)
Derate linearly 11.4 mW/°C for TA > +25°C.
(4)
Derate linearly 250 mW/°C for TC > +100°C.
(5)
Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime ATTN:
VAC, P.O. Box 3990, Columbus, OH 432183990, or emailed to semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.dla.mil.
