MILPRF19500/472F
TABLE I. Group A inspection Continued.
Limit
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 5 Continued.
TC = +100°C; t ≥ 1.0 s, 1 cycle;
Safe operating area
3051
(continuous dc)
(for types 2N6352 and
RB2E = 100 ohms
2N6353 only)
Test 1
(2N6352, 2N6353)
VCE = 5.0 V dc; IC = 5 A dc
Test 2
(2N6352, 2N6353)
VCE = 10 V dc; IC = 2.5 A dc
Test 3
(2N6352)
VCE = 80 V dc; IC = 95 mA dc
Test 4
(2N6353)
VCE = 150 V dc; IC = 35 mA dc
Electrical measurements
See subgroup 2 of table I
Safe operating area
3053
Load condition B (clamped
(switching)
inductive load) see figure 8;
TA = + 100°C; tr + tf ≤ 1.0 µs;
duty cycle ≤ 2 percent;
tp = 8 ms (vary to obtain IC);
Rs = 0.1 Ω; RBB1 = 200 Ω;
VBB1 = 10 V dc; RBB2 = 2.2 kΩ;
VBB2 = 4 V dc; IC = 5 A dc;
VCC = 25 V dc; RL ≤ 2.5 Ω;
L = 40 mH (Triad c-48U, or
equivalent); RB2E = 100 Ω
2N6350, 2N6352
Clamp voltage = 50 +0, 5 V dc
2N6351, 2N6353
Clamp voltage = 90 +0, 5 V dc
Electrical measurements
See subgroup 2 of table I
1/
For sampling plan, see MILPRF19500.
2/
This test required for the following end-point measurements only:
Group B, subgroups 2 and 3 (JAN, JANTX, and JANTXV).
Group C, subgroup 2 and 6.
Group E, subgroup 1.
