MILPRF19500/472F
Dimensions
Symbol
Inches
Millimeters
Notes
Min
Max
Min
Max
CD
.305
.335
7.75
8.51
3
CH
.184
.260
4.67
6.60
HD
.335
.370
8.51
9.40
LC
0.200 TP
5.080 TP
4
LD
.016
.021
0.407
0.533
5, 6
LL
1.500
1.750
38.10
44.45
5, 6
L1
.050
1.27
5, 6
L2
.250
6.35
5, 6
LU
.016
.019
0.407
0.482
5, 6
TL
.029
.045
0.74
1.14
7
TW
.028
.034
0.712
0.863
8
P
.100
2.54
3
Q
.050
1.27
9
r
.010
0.254
10
α
45° TP
45° TP
4
NOTES:
1. Dimensions are in inches. Millimeters are given for general information only.
2. Internal resistance (typically 750 ohms). This resistor is optional.
3. Dimension CD shall not vary more than .010 inch (0.25 mm) in zone P. This zone is controlled for
automatic handling.
4. Leads at gauge plane .054 +.001 .000 inch (1.37 +0.03 0.00 mm) below seating plane shall be within
.007 inch (0.18 mm) radius of true position (TP) at maximum material condition (MMC) relative to tab at
MMC. The device may be measured by direct methods.
5. Dimension LU applies between dimension L1 and dimension L2. Dimension LD applies between L2 and LL
minimum. Diameter is uncontrolled in dimension L1 and beyond dimension LL minimum.
6. All terminals.
7. Dimension TL measured from maximum HD.
8. Beyond r (radius) maximum, dimension TW shall be held for a minimum length of .011 inch (0.28 mm).
9. Outline in this zone is not controlled.
10. The radius (dimension r) applies to both inside corners of the tab.
11. Terminal designation is as follows: 1 emitter, 2 base (B2), 3 base (B1), 4 collector. The collector
shall be connected to the case.
12. In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.
FIGURE 1. Physical dimensions (TO33) and schematic circuit for 2N6350 and 2N6351 Continued.
