MIL-PRF-19500/503H
* 4.3 Screening (JANTX and JANTXV levels). Screening shall be in accordance with appendix E, table E-IV of
MIL-PRF-19500, and as specified herein. The following measurements shall be made in accordance with table I
herein. Devices that exceed the limits of table I herein shall not be acceptable.
Screen (see appendix
JANTXV and JANTX Level
E, table E-IV of
1a
Not required
1b
Required (JANTXV only)
2
Not required
3a
Required
3c
Thermal impedance (see 4.3.1)
4
Not applicable
5
Not applicable
6
Not applicable
8
Not required
Not applicable
9
TA = +125°C
10
VF1 and IR1
11
12
Required, see 4.3.2
13
Subgroup 2 of table I herein;
ĆVF1 = ±0.1V dc;
*
ĆIR1 = (1) or 100 percent of the initial value, whichever
is greater. Scope display evaluation (see 4.5.3).
15
Not required
16
Not required
(1) IR1 is as follows:
1N6073 through 1N6075 = +0.250 µA dc.
1N6076 through 1N6078 = +1.0 µA dc.
1N6079 through 1N6081 = +5.0 µA dc.
4.3.1 Thermal impedance. The thermal impedance measurements shall be performed in accordance with method
3131 of MIL-STD-750 using the guidelines in that method for determining IM, IH, tH, tSW (VC and VH where
4.3.1.1 For initial qualification and re-qualification. Read and record data (ZθJX) shall be supplied to the qualifying
activity on one lot (random sample of 500 devices minimum) prior to shipment. Twenty-two samples shall be
serialized and provided to the qualifying activity for test correlation.
4.3.2 Power burn-in conditions. Power burn-in conditions are as follows (see 4.5.6.1): IO(min) = IO(rated). TA =
55°C maximum. Test conditions in accordance with method 1038 of MIL-STD-750, condition B. Adjust IO or TA to
achieve the required TJ. TJ = 135°C minimum. With approval of the qualifying activity and preparing activity,
alternate burn-in criteria (hours, bias conditions, TJ, mounting conditions) may be used for JANTX and JANTXV
quality levels. A justification demonstrating equivalence is required. In addition, the manufacturing site's burn-in data
and performance history will be essential criteria for burn-in modification approval.
4.3.3 Screening (JANHC). Screening of die shall be in accordance with appendix G of MIL-PRF-19500. As a
minimum, die shall be 100-percent probed to ensure compliance with table I, subgroup 2. Burn-in duration for the
JANHC follows JANTX requirements.
6
