INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/596K
shall be completed by 1 June 2013.
17 April 2013
SUPERSEDING
MIL-PRF-19500/596J
14 April 2009
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, REPETITIVE AVALANCHE, FIELD EFFECT,
TRANSISTOR, N-CHANNEL, SILICON,
TYPES 2N7218, 2N7219, 2N7221, 2N7222, 2N7218U, 2N7219U,
2N7221U, AND 2N7222U, JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for a N-channel, enhancement mode,
MOSFET, power transistor intended for use in high density power switching applications. Four levels of product
assurance are provided for each device type as specified in MIL-PRF-19500, with avalanche energy maximum
ratings (EAR and EAS) and maximum avalanche current IAR. Two levels of product assurance are provided for die
(element evaluation).
1.2 Physical dimensions. See figure 1 (TO-254AA), figure 2 for JANHC and JANKC (die) dimensions, and figure 3
for surface mount (TO-267AB).
1.3 Maximum ratings. Unless otherwise specified, TC = +25°C.
Type
PT (1)
PT
V(BR)DSS min
ID1 (3) (4) ID2 (3) (4)
IS
IDM
TJ
RθJC
TC =
TA =
(2)
VGS = 0
TC =
TC =
(5)
and
+25°C
+25°C
+25°C
+100°C
ID = 1.0 mA dc
TSTG
°C/W
°C
W
W
V dc
A dc
A dc
A dc
A (pk)
2N7218, 2N7218U
125
4
100
28
20
28
112
1.0
-55 to +150
2N7219, 2N7219U
125
4
1.0
200
18
11
18
72
-55 to +150
2N7221, 2N7221U
125
4
1.0
400
10
6
10
40
-55 to +150
2N7222, 2N7222U
125
4
1.0
500
8
5
8
32
-55 to +150
See notes next page.
Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
*
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dla.mil. Since contact information can change, you may want to verify the currency of this
address information using the ASSIST Online database at https://assist.dla.mil/.
AMSC N/A
FSC 5961
