MIL-PRF-19500-596 Semiconductor Device, Repetitive Avalanche, Field Effect, Transistor, N-Channel, Silicon, Types 2N7218, 2N7219, 2N7221, 2N7222, 2N7218U, 2N7219U, 2N7221U, And 2N7222U, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for a N-channel, enhancement mode, MOSFET, power transistor intended for use in high density power switching applications. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500, with avalanche energy maximum ratings \(EAR and EAS\) and maximum avalanche current IAR. Two levels of product assurance are provided for die \(element evaluation\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


MIL-PRF-19500/596K
TABLE I. Group A inspection - Continued.
Inspection
MIL-STD-750
Limits
Symbol
Unit
1/
Method
Condition
Min
Max
Subgroup 7
Gate charge
3471
Condition B
On-state gate charge
Qg(on)
2N7218, 2N7218U
59
nC
2N7219, 2N7219U
60
nC
2N7221, 2N7221U
65
nC
2N7222, 2N7222U
68.5
nC
Gate to source charge
Qgs
2N7218, 2N7218U
16
nC
2N7219, 2N7219U
14.6
nC
2N7221, 2N7221U
14.0
nC
2N7222, 2N7222U
12.5
nC
Gate to drain charge
Qgd
2N7218, 2N7218U
30.7
nC
2N7219, 2N7219U
37.6
nC
2N7221, 2N7221U
40.5
nC
2N7222, 2N7222U
42.4
nC
di/dt ≤ 100 A/µs, VDD ≤ 30 V,
Reverse recovery time
3473
trr
ID = ID1, (see 1.3)
2N7218, 2N7218U
400
ns
2N7219, 2N7219U
500
ns
2N7221, 2N7221U
600
ns
2N7222, 2N7222U
700
ns
1/ For sampling plan, see MIL-PRF-19500.
2/ This test required for the following end-point measurements only:
Group B, subgroups 3 and 4 (JANS).
Group B, subgroups 2 and 3 (JANTXV).
Group C, subgroups 2 and 6.
Group E, subgroup 1.
14
