The documentation and process conversion
INCH-POUND
measures necessary to comply with this document
shall be completed by 20 January 2014.
MIL-PRF-19500/605D
20 November 2013
SUPERSEDING
MIL-PRF-19500/605C
16 April 2008
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, FIELD EFFECT RADIATION HARDENED (TOTAL DOSE ONLY)
TRANSISTORS, N-CHANNEL, SILICON, TYPES 2N7292, 2N7294, 2N7296, AND 2N7298,
JANTXVM, D, R, H AND JANSM, D AND R
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for an N-Channel, enhancement-mode,
MOSFET, radiation hardened (total dose only), power transistor intended for use in high density power switching
applications. Two levels of product assurance are provided for each device type specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (similar to TO-254).
1.3 Maximum ratings (TC = +25°C, unless otherwise specified).
Type
PT (1)
PT
VDS
VDG
VGS
ID1 (2)
ID2 (2)
IS
IDM
TJ
VISO
(2)
(3)
and
70,000
TC =
TA =
TC =
TC =
+25°C
+25°C
+25°C
+100°C
feet
TSTG
altitude
°C
W
W
V dc
V dc
A dc
A dc
A dc
A dc
A(pk)
V dc
±20
2N7292
125
2.5
100
100
25
20
25
75
-55 to +150
N/A
±20
2N7294
125
2.5
200
200
23
15
23
69
-55 to +150
N/A
±20
2N7296
125
2.5
250
250
17
11
17
51
-55 to +150
250
±20
2N7298
125
2.5
500
500
9
6
9
27
-55 to +150
500
(1) Derate linearly 1.0 W/°C for TC > +25°C.
(2) The following formula derives the maximum theoretical ID limit. ID is limited by package and internal wires and
may be limited by pin diameter:
TJM - TC
ID = (
RθJC ) x ( R DS ( on ) at TJM )
(3) IDM = 4 x ID as calculated by note (2).
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since
contact information can change, you may want to verify the currency of this address information using the
ASSIST Online database at https://assist.dla.mil/.
AMSC N/A
FSC 5961
