MIL-PRF-19500/182H
* TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Limit
Unit
Symbol
Method
Conditions
Min
Max
Subgroup 2 - Continued
Collector-emitter
3071
1.2
V dc
IC = 50 mA dc, IB = 5 mA dc,
VCE(sat)2
saturated voltage
pulsed (see 4.5.1)
3066
Base-emitter saturated
1.3
V dc
Test condition A, IC = 150 mA dc,
VBE(sat)1
voltage
Base-emitter saturated
3066
1.2
V dc
Test condition A, IC = 50 mA dc,
VBE(sat)2
voltage
Forward-current transfer ratio
3076
20
VCE = 10 V dc, IC = 0.1 mA dc,
hFE1
pulsed (see 4.5.1)
Forward-current transfer ratio
3076
35
VCE = 10 V dc, IC = 10 mA dc,
hFE2
pulsed (see 4.5.1)
Forward-current transfer ratio
3076
40
120
VCE = 10 V dc, IC = 150 mA dc,
hFE3
pulsed (see 4.5.1)
Subgroup 3
High temperature
TA = +150°C
operation:
15
Collector to base cutoff current
3036
µA dc
Bias condition D, VCB = 90 V dc
ICBO3
Low temperature
TA = -55°C
operation
Forward-current transfer
3076
20
VCE = 10 V dc, IC = 10 mA dc,
hFE4
ratio
pulsed (see 4.5.1)
Subgroup 4
Small signal short circuit forward
3206
35
100
VCE = 5 V dc, f = 1 kHz,
hfe
current transfer ratio
IC = 1 mA dc:
45
150
VCE = 10 V dc, f = 1 kHz,
hfe
IC = 5 mA dc
3
10
Magnitude of common emitter
3306
|hfe|
VCE = 10 V dc, f = 20 MHz,
small-signal short-circuit
IC = 50 mA dc
forward-current transfer ratio
Small signal short circuit input
3201
4
8
ohms
VCB = 10 V dc,
hib
impedance
IC = 5 mA dc
