MIL-PRF-19500/182H

* TABLE III. Group E inspection (all quality levels) - for qualification or re-qualification only.

MIL-STD-750

Qualification

Inspection

Method

Conditions

Subgroup 1

45 devices

c=0

1051

Test condition C, 500 cycles

Temperature cycling

(air to air)

1071

Hermetic seal

Fine leak

Gross leak

See table I, subgroup 2 herein.

Electrical measurements

45 devices

Subgroup 2

c=0

1037

Intermittent life

Intermittent operation life: VCB = 10 V dc, 6,000 cycles. Adjust

device current, or power, to achieve a minimum ĆTJ of +100�C.

Electrical measurements

See table I, subgroup 2 herein.

Subgroup 4

Thermal resistance

3131

15 devices,

RθJSP(IS) can be calculated but shall be measured once in the

c=0

same package with a similar die size to confirm calculations

(may apply to multiple specification sheets).

Thermal impedance

See table E-IX of MIL-PRF-19500, group E, subgroup 4.

Sample size

curves.

N/A

Subgroup 5

Not applicable

Subgroup 8

45 devices

c=0

Reverse stability

1033

Condition B.
