MIL-PRF-19500/429N
TABLE III. Groups B, C, and E delta measurements. 1/ 2/ 3/ 4/ 5/
Step
Inspection
Symbol
Limits
Unit
MIL-STD-750
Method
Conditions
Min
Max
ĆIR1
1.
Reverse current leaking
4016
DC method
For JAN, JANTX,
and JANTXV, ≤ 250
change
nA dc or 100
1N5615, US
VR = 200 V
percent, whichever
1N5617, US
VR = 400 V
is greater; for JANS,
1N5619, US
VR = 600 V
≤ 100 nA dc or 100
1N5621, US
VR = 800 V
percent, whichever
1N5623, US
VR = 1,000 V
is greater.
±50 mV dc
ĆVF1
2.
Forward voltage change
4011
IF = 3 A dc;
maximum change
pulsed (see
from previous
measured value.
µs; 2 percent
maximum duty
cycle.
Devices which exceed the table I, subgroup 2 (group A) limits for this test shall not be accepted.
1/
2/
The delta measurements for group B inspections in table E-VIA (JANS) of MIL-PRF-19500 are as follows:
a. Subgroup 3, see table III herein, steps 1 and 2.
b. Subgroup 4, see table III herein, step 2.
c. Subgroup 5, see table III herein, steps 1 and 2.
3/
The delta measurements for group B inspections in table E-VIB (JAN, JANTX, and JANTXV) of
MIL-PRF-19500 are as follows:
a. Subgroup 3, see table III herein, steps 1 and 2.
b. Subgroup 6, see table III herein, step 1.
The delta measurements for group C inspections in table E-VII of MIL-PRF-19500 are as follows:
4/
a. Subgroup 2, see table III herein, step 1 (JANS).
b. Subgroup 6, see table III herein, steps 1 and 2 (JANS), step 1 (JAN, JANTX, and JANTXV).
The delta measurements for group E inspections in table E-IX of MIL-PRF-19500 are: Subgroups 1 and 2,
5/
see table III herein, steps 1 and 2.
16
